Cloud based solution with a web based interface for use with a laptop or with our mobile apps built for iOS and Android!

Developed and tested in-house from the ground up since its debut in November 2016 with new features and updates being added regularly makes the bootmod3 platform a custom BMW factory DME tuning solution like no other on the market since.

Build the ultimate tune for your B48 / B46 engine powered vehicle and go from stock to full race calibration, and everywhere in between, with a map switch in the provided mobile app. bootmod3 calibrates the factory vehicle modules over the OBD port in a matter of minutes in the convenience of your driveway or anywhere internet access is available.

20i models:
Stage 1 91 octane: up to 42% HP / 46% TQ
Stage 1 93 octane: up to 46% HP / 48% TQ
Stage 1 E30 octane: up to 53 % HP / 50% TQ
Stage 2 91 octane: up to 50% HP / 48% TQ
Stage 2 93 octane: up to 54% HP / 50% TQ
Stage 2 E30 octane: up to 60% HP / 55% TQ

30i models:
Stage 1 91 octane: up to 14% HP / 26% TQ
Stage 1 93 octane: up to 16% HP / 26% TQ
Stage 1 E30 octane: up to 20% HP / 28% TQ
Stage 2 91 octane: up to 16% HP / 28% TQ
Stage 2 93 octane: up to 18% HP / 28% TQ
Stage 2 E30 octane: up to 22% HP / 30% TQ
Stage 2 AGG (Aggressive burble) versions of maps available
Race gas maps are on the way!

For the additional OTS maps bundle, please see Bootmod3 BMW B48 F Chassis OTS Maps Bundle (Inc. 125i, 320i, 430i & 530i).

You may also wish to add the Boostmod3 OBD Agent Wifi Device and ML Performance BMW F & G Series OBDII to ENET Cable

Please Note: This BM3 License code will be automatically sent via email upon your order!

• Mobile app (iOS and Android) and Web (http://www.bootmod3.net)
• One OTS map/tune included with the purchase
• Datalogging hundreds of diagnostic channels, up to 40 channels concurrently
• Datalog sharing and charting without a need to upload to 3rd party websites or apps using the mobile app or web browser
• Cloud based storage for map data and datalogs
• Reverting back to stock performance map and re-locking the DME to stock programming
• Live Dash - realtime vehicle parameter monitoring via in-app guages
• Diagnostics
• Read and clear trouble codes in all vehicle modules
• Reset learned adaptations (octane, knock, Valvetronic, etc)
• ECU power reset
• (Optional) Acquire a full OTS Map bundle to gain access to all OTS maps offered
• (Optional) Custom tuning available through tuners in the bootmod3 Tuner Directory. bootmod3 contains a full map editor so you can tune your car yourself or with your local tuner of choice as well.

Some of the OTS and possible aftermarket turbo upgrade custom map features provided by the bootmod3 platform :

• Top speed limiter removal
• Exhaust burble adjustments in app on any map (OTS and custom)
• Exhaust flap adjustments
• Cold start (cat heating on startup) removal for quieter cold start
• Cat efficiency check (CEL) removal for de-cat downpipes (for off-road use)
• Maps for upgraded turbos
• E85, race gas and meth injection tuning
• Custom Throttle mapping

For more info take a look at the FAQ here!

*** OBD ENET cable required, available separately

*** bootmod3 OBD WiFi Agent device is not required to use the bootmod3 platform. It is a convenience option that removes the need for using a laptop in the car when using bootmod3's features. If you're looking to simply load a tune on the car without much datalogging and monitoring then using your laptop is the ticket for you.

For more information please email us at info@mlperformance.co.uk or refer to our Instagram and Facebook accounts.

B48 / B46 engine BMW Vehicles supported (if your vehicle is not listed please inquire with us):

• 2016–2019 F20/F21 120i/125i
• 2016–present F22/F23 220i/230i
• 2016–2019 F30/F31/F34 320i/330i including Hybrid 330e
• 2016–present F32/F33 420i/430i
• 2016-present F36 420i/430i
• 2017–present G30/G31 520i/530i including Hybrid 530e
• 2017-present G01 X3 20i/30i
• 2018-present G02 X4 20i/30i
• 2019 - current G20 320i 330i
• 2019 - current G30 520i 530i
• 2019 - current G01/G02 X3/X4 20i 25i 30i
• 2019 - current G05 X5 30i
• 2019 - current G11/G12 730i
• 2016 - current F56 Mini Cooper S

Note:

• If your car is a March 2019+ model, you may need to visit one of our partner garages to have the car bench unlocked before you can flash your ECU. Please contact us to know more.
• Cars with the latest 2019+ BMW software can also be affected and may require a bench unlock to flash over OBD.

Hardware Requirement

*** OBD ENET cable required, available separately

*** bootmod3 OBD WiFi Agent device is not required to use the bootmod3 platform. It is a convenience option that removes the need for using a laptop in the car when using bootmod3's features. If you're looking to simply load a tune on the car without much datalogging and monitoring then using your laptop is the ticket for you.

DME removal from the engine bay for unlocking OBD programming is NO LONGER REQUIRED. However, Vehicles with November 2019+ software updates MAY require DME unlock done on the bench to enable OBD flashing. If required you can visit one of our partner garages to have the car bench unlocked before you can flash your ECU. Please contact us to know more.

VEHICLE MANUFACTURER WARRANTY AND EMISSIONS DISCLAIMER

Some items used and/or installed by PRO TUNING FREAKS may void portions of your vehicle’s factory warranty. Some items may not be legal for “on highway use”. PRO TUNING FREAKS makes no guarantees to the legality of any parts used for “on highway vehicles” and accepts no responsibility for compliance with the vehicle’s factory warranty.

BM3-B48
