PAGID Racing STREET+ Brake Pads - T8242SP2001

Similar to PAGID Racing brake pads, the STREET+ by PAGID Racing features a dual retention system that combines an adhesive bond with a unique mechanical system. The mechanical system on STREET+ by PAGID Racing includes a crimped backplate interface with the friction material, ensuring a stronger bond between the friction material and the backplate.

STREET+ Axle Set No: T8242SP2001
, Compliance: R90 - Suitable for road use.

Specification

Width [mm]: 98.7
Height [mm]: 40
Thickness [mm]: 14.9
Wear Warning Contact: with acoustic wear warning

OEM Cross Reference
Manufacturer Reference
NISSAN
D4M603AW0A
SUZUKI
5580052R00
SUZUKI
5580052R00000
SUZUKI
5580052R01
SUZUKI
5580052R01000
SUZUKI
5580061M00
SUZUKI
5580061M00000
SUZUKI
5580061M01
SUZUKI
5580061M01000
SUZUKI
5580061M02
SUZUKI
5580061M02000
SUZUKI
5580061M10
SUZUKI
5580061M11
SUZUKI
5580068L00
SUZUKI
5580068L00000
SUZUKI
5580068L10
SUZUKI
5580068L10000
SUZUKI
5580068L20
SUZUKI
5580068L20000
SUZUKI
5580068L21
SUZUKI
5580068L21000
SUZUKI
5580068R00
SUZUKI
5580068R00000
SUZUKI
5580068R10
SUZUKI
5580068R10000
SUZUKI
5580068R11
SUZUKI
55910M68P00
SUZUKI
55910M68P00000
SUZUKI
55910M68P01
SUZUKI
55910M68P01000
PAGID STREET+ Unique Double Retention System
  • Developed with expertise transferred from racing technology
  • Friction material is mechanically secured to the backplate
  • No delamination of friction material from the steel backplate
  • Motorsport high-tech and innovation for your vehicle

The STREET+ friction compound by PAGID Racing integrates decades of racing experience into a street-legal product that complies with the latest environmental standards. Equipped with anti-noise shims and fully accessorized as an aftermarket brake pad range, this compound exclusively uses the mechanical retention system found in all PAGID Racing brake pads. This race-inspired technology provides an ideal solution for drivers starting track activities.

Bedding In for PAGID STREET+ Brake Pads

After installing new brake discs and pads, it is essential to bed in the friction surfaces. This ensures they adapt properly to one another for safe and optimal brake performance.

If not bedded in correctly, uneven material transfer between the pad and disc or uneven distribution of deposits may occur, potentially leading to vibrations or noise issues. Warranty is voided for all pads exhibiting symptoms of not being bedded in correctly.



Weight 3.2 kg
Dimensions 20 x 12 x 12 cm
Axle Fitment

Rear



Manufacturer Model Engine / cc Years Engine Code Bodytype Fuel
SUZUKI BALENO (FW, EW) 1.0 (A1K310) / 111hp / 998cc 2016 - 2025 K10C-T Hatchback Petrol
SUZUKI BALENO (FW, EW) 1.2 (A1K412) / 90hp / 1242cc 2016 - 2025 K12C Hatchback Petrol
SUZUKI BALENO (FW, EW) 1.2 Hybrid (A1K412) / 90hp / 1242cc 2016 - 2025 K12C Hatchback Petrol/Electric
SUZUKI S-CROSS 1.4 Smart Hybrid (AKP414) / 129hp / 1373cc 2022 - 2025 K14D SUV Petrol/Electric
SUZUKI S-CROSS 1.4 Smart Hybrid AllGrip (AKP414) / 129hp / 1373cc 2022 - 2025 K14D SUV Petrol/Electric
SUZUKI S-CROSS 1.5 Hybrid (AKK415) / 116hp / 1462cc 2022 - 2025 K15C SUV Petrol/Electric
SUZUKI S-CROSS 1.5 Hybrid AllGrip (AKK415) / 116hp / 1462cc 2022 - 2025 K15C SUV Petrol/Electric
SUZUKI SWIFT III (FZ, NZ) 1.2 (AZG412, ZC72S) / 90hp / 1242cc 2010 - 2025 K12B Hatchback Petrol
SUZUKI SWIFT III (FZ, NZ) 1.2 (AZH412, AZG412, ZC72S) / 91hp / 1242cc 2012 - 2025 K12B Hatchback Petrol
SUZUKI SWIFT III (FZ, NZ) 1.2 (AZH412, ZC72S) / 94hp / 1242cc 2010 - 2025 K12B Hatchback Petrol
SUZUKI SWIFT III (FZ, NZ) 1.2 4WD (AZH412, AZG412, ZD72S) / 91hp / 1242cc 2012 - 2025 K12B Hatchback Petrol
SUZUKI SWIFT III (FZ, NZ) 1.2 4x4 (AZG412, ZD72S) / 90hp / 1242cc 2010 - 2025 K12B Hatchback Petrol
SUZUKI SWIFT III (FZ, NZ) 1.2 4x4 (AZH412, ZD72S) / 94hp / 1242cc 2010 - 2025 K12B Hatchback Petrol
SUZUKI SWIFT III (FZ, NZ) 1.3 DDiS (AZG413D, ZC02S, ZC92S) / 75hp / 1248cc 2010 - 2025 D13A/D13AA Hatchback Diesel
SUZUKI SWIFT III (FZ, NZ) 1.6 (AZG416, AZH416, RS416, ZC32S, ZA32S) / 136hp / 1586cc 2012 - 2025 M16A Hatchback Petrol
SUZUKI SWIFT V (AZ) 1.0 (A2L310) / 111hp / 998cc 2017 - 2025 K10C-T Hatchback Petrol
SUZUKI SWIFT V (AZ) 1.0 SHVS (A2L310) / 111hp / 998cc 2017 - 2025 K10C-T Hatchback Petrol/Electric
SUZUKI SWIFT V (AZ) 1.2 (A2L412, ZC83S) / 90hp / 1242cc 2017 - 2025 K12C Hatchback Petrol
SUZUKI SWIFT V (AZ) 1.2 AllGrip (A2L412) / 90hp / 1242cc 2017 - 2025 K12C Hatchback Petrol
SUZUKI SWIFT V (AZ) 1.2 Hybrid (Mild Hybrid) (A2L412) / 83hp / 1197cc 2020 - 2025 K12D Hatchback Petrol/Electric
SUZUKI SWIFT V (AZ) 1.2 Hybrid (Mild Hybrid) AllGrip (A2L412) / 83hp / 1197cc 2020 - 2025 K12D Hatchback Petrol/Electric
SUZUKI SWIFT V (AZ) 1.2 SHVS (A2L412) / 90hp / 1242cc 2017 - 2025 K12CS Hatchback Petrol/Electric
SUZUKI SWIFT V (AZ) 1.2 SHVS AllGrip (A2L412) / 90hp / 1242cc 2017 - 2025 K12CS Hatchback Petrol/Electric
SUZUKI SWIFT V (AZ) 1.4 Sport (A2L414, ZC33S) / 140hp / 1373cc 2017 - 2025 K14C Hatchback Petrol
SUZUKI SWIFT V (AZ) 1.4 Sport SHVS / 129hp / 1373cc 2020 - 2025 K14D Hatchback Petrol/Electric
SUZUKI SX4 S-CROSS (JY) 1.0 (AKK 310) / 111hp / 998cc 2016 - 2025 K10C-T Hatchback Petrol
SUZUKI SX4 S-CROSS (JY) 1.0 AllGrip (AKK 310) / 111hp / 998cc 2016 - 2025 K10C-T Hatchback Petrol
SUZUKI SX4 S-CROSS (JY) 1.4 Hybrid (Mild Hybrid) (AKK 414) / 129hp / 1373cc 2019 - 2025 K14D Hatchback Petrol/Electric
SUZUKI SX4 S-CROSS (JY) 1.4 Hybrid (Mild Hybrid) AllGrip (AKK 414) / 129hp / 1373cc 2019 - 2025 K14D Hatchback Petrol/Electric
SUZUKI SX4 S-CROSS (JY) 1.4 T (AKK414) / 140hp / 1373cc 2016 - 2025 K14C Hatchback Petrol
SUZUKI SX4 S-CROSS (JY) 1.4 T AllGrip (AKK414) / 140hp / 1373cc 2016 - 2025 K14C Hatchback Petrol
SUZUKI SX4 S-CROSS (JY) 1.6 (AKK 416) / 120hp / 1586cc 2013 - 2025 M16A Hatchback Petrol
SUZUKI SX4 S-CROSS (JY) 1.6 (AKK416, YA22S) / 117hp / 1586cc 2013 - 2025 M16A Hatchback Petrol
SUZUKI SX4 S-CROSS (JY) 1.6 AllGrip (AKK 416) / 120hp / 1586cc 2013 - 2025 M16A Hatchback Petrol
SUZUKI SX4 S-CROSS (JY) 1.6 AllGrip (AKK416, YB22S) / 117hp / 1586cc 2013 - 2025 M16A Hatchback Petrol
SUZUKI SX4 S-CROSS (JY) 1.6 DDiS (AKK 416D) / 120hp / 1598cc 2013 - 2025 D16AA Hatchback Diesel
SUZUKI SX4 S-CROSS (JY) 1.6 DDiS AllGrip (AKK 416D) / 120hp / 1598cc 2013 - 2025 D16AA Hatchback Diesel
SUZUKI VITARA (LY) 1.0 (APK 310) / 111hp / 998cc 2018 - 2025 K10C-T SUV Petrol
SUZUKI VITARA (LY) 1.0 AllGrip (APK 310) / 111hp / 998cc 2018 - 2025 K10C-T SUV Petrol
SUZUKI VITARA (LY) 1.4 Hybrid (Mild Hybrid) (APK414) / 129hp / 1373cc 2019 - 2025 K14D SUV Petrol/Electric
SUZUKI VITARA (LY) 1.4 Hybrid (Mild Hybrid) AllGrip / 129hp / 1373cc 2023 - 2025 K14D SUV Petrol/Electric/Biogas
SUZUKI VITARA (LY) 1.4 Hybrid (Mild Hybrid) AllGrip (APK414) / 129hp / 1373cc 2019 - 2025 K14D SUV Petrol/Electric
SUZUKI VITARA (LY) 1.4 T (APK414) / 140hp / 1373cc 2015 - 2025 K14C SUV Petrol
SUZUKI VITARA (LY) 1.4 T AllGrip (APK414) / 140hp / 1373cc 2015 - 2025 K14C SUV Petrol
SUZUKI VITARA (LY) 1.6 (APK 416) / 120hp / 1586cc 2015 - 2025 M16A SUV Petrol
SUZUKI VITARA (LY) 1.6 (APK416, YD21S) / 117hp / 1586cc 2015 - 2025 M16A SUV Petrol
SUZUKI VITARA (LY) 1.6 AllGrip (APK 416) / 120hp / 1586cc 2015 - 2025 M16A SUV Petrol
SUZUKI VITARA (LY) 1.6 AllGrip (APK416, YE21S) / 117hp / 1586cc 2015 - 2025 M16A SUV Petrol
SUZUKI VITARA (LY) 1.6 DDiS (APK 416D) / 120hp / 1598cc 2015 - 2025 D16AA SUV Diesel
SUZUKI VITARA (LY) 1.6 DDiS AllGrip (APK416D) / 120hp / 1598cc 2015 - 2025 D16AA SUV Diesel

Feel free to contact us at info@mlperformance.co.uk should you wish to double check!



To ensure the part(s) you have ordered fits your vehicle, we run a compatibility check prior to dispatch. We can do this either using your registration number (UK) or the last 7 digits of your VIN. Simply enter your car details prior to checkout.
