ST Suspensions

ST Suspensions 182100AJ Audi 8V A3 COILOVER KIT XA

ST Suspensions 182100AJ Audi 8V A3 COILOVER KIT XA

Regular price £1,085.00 Inc. VAT
Regular price £1,085.00 Sale price £1,085.00 Inc. VAT
9th Anniversary Badge

Price Match

In Stock

Receive your order by tomorrow if ordered within
00 hours
00 mins
00s.

Get It By

Receive your order tomorrow. Subject to availability.

Collect 0 points

Purchasing this product will earn you 0 loyalty points worth £0.00 GBP.

Price Match Guarantee

If you find a lower price at an eligible UK retailer website, we will match it.

Fitting service at Xatrix, West Yorkshire

We can offer a fitting service for this part. Contact us for a fitting quote.

UNLOCK BIGGER DISCOUNTS WITH ML PLATINUM
Sign Up

Sign up now for FREE

View full details
For drivers wanting more than just ride height adjustment comes the ST XA coilover. Developed alongside KW Automotive the ST XA allows individual adjustment of the damping to suit just about all your driving needs!

Perfect for sporty driving
ST XA coilovers feature KW damping technology which allows the suspension to be made either stiffer or softer depending on the driving conditions. This damping adjustment is made on the upper end of the chromed piston rod allowing the setup to be changed almost instantly. If the rebound force is increased, the car will drive with even more track stability and further reduced bodyroll. If the rebound force is decreased, the car will feel more comfortable when on the move. Any vehicle fitted with ST XA coilovers will act much more agile and sporty compared to standard.

Easy lowering adjustment
Like all ST coilovers the lowering adjustment is made via a continuous thread on the galvanized strut. This even allows the lowering to be made even when the kit is installed by turning the spring plate higher or lower! NOTE: The lowering of each vehicle differs greatly with ST XA coilovers due to the type of construction. For example, older vehicles such as the Honda Civic (EJ9) can be lowered between 40-75mm with ST XA coilovers, while newer models such as the Audi S3 (8P) can be lowered between 10-40mm due to being much lower from the factory.

KW Engineering: Exclusive for ST suspension
The high-quality ST XA coilover is based on the twin-tube damping principle of low friction combined with pressure-resistant damper housings. Manufactured directly at KW, a mono block guide and seal package reduces the friction of the damper as well as protecting it against corrosion and dirt. Each galvanized strut is sealed multiple times to ensure maximum longevity in ALL weath



    • Front Lowering: 30mm to 60mm
    • Rear Lowering: 30mm to 55mm
    • Version: ST XA
    • Damping adjustment: None
    • Material: Galvanized Steel
    • Strut diameter front axle (mm): 50
    • Rear axle type: Multi-link rear axle (independent wheel suspension)
    • Approval: Part approval (ง19.3)



    Specifications

    Length 76
    Width 46
    Height 15



    • A3
      • A3 Hatchback (8V1, 8VK) (04/2012-)
        • 1.8tfsi quattro / 2.0tdi quattro / 2.0tfsi quattro
      • A3 Saloon (8VS, 8VM) (05/2013-)
        • 1.6tdi quattro / 1.8tfsi quattro / 2.0tdi quattro / 2.0tfsi quattro / 40tdi quattro / 40tfsi quattro
      • A3 Sportback (8VA, 8VF) (09/2012-)
        • 1.6tdi quattro / 1.8tfsi quattro / 2.0tdi quattro / 2.0tfsi quattro / 40tdi quattro / 40tfsi quattro

    Note:

    • Only for cars with a clamp diameter of 50 mm on the front axle.
    • At vehicles equipped with electronic damping, the electronic damping control needs to be deactivated. Deactivation kit KW Part-no. 68510424



    To ensure the part(s) you have ordered fits your vehicle, we run a compatibility check prior to dispatch. We can do this either using your registration number (UK) or the last 7 digits of your VIN. Simply enter your car details prior to checkout.



    182100AJ


    Manufactured by

    ST Suspension


    Warranty

    Two years manufacturer warranty



    EAN

    4250580474388
