Lightwave Amplifier

For pre-2018 Harman Kardon (688), Individual (752) & HiFi Professional (677)

A complete music experience with Alpha One Amplifier.

If you want your music to exceed what’s commonly the BEST and become YOURS, complete the set with the Alpha One amplifier upgrade.

Thanks to the DSP tuning, our engineers can customize your sound according to the car chassis and musical preferences, so that your sound comes out as good as possible right off the bat.

One & Only Customized Audio System

• Customizable tune & mounting hardware for your BMW or MINI
• Up to 10 preset tuning files to switch according to your musical preferences
• Augmented bass processing digitally expands bass capabilities
• Hefty power output of RMS 710-840W and 1420-1680W MAX
• Simple plug & play DIY installation
• 2-year warranty and individual support of Audio Engineer

Lightwave Amplifier – It's a match!

• Less conversion
  • for accurate sound quality, thanks to a built-in transceiver
• 2300W max
  • total output, at least 3 times as much as stock
• High-end upgrade
  • for optical systems like Harman Kardon or Individual Audio
• 9 channels
  • with one 500W max power output for additional subwoofer
• Selectable tunes
  • that you can choose from directly in your iDrive

Want to feel the quality of a custom-built studio system in the comfort of your BMW cabin? Then search no more: we've got the first high-end direct upgrade amplifier for BMWs with Top Hi-Fi optical audio systems like Logic 7, Individual Audio, or Harman Kardon.

Enjoy the highest fidelity of sound thanks to as little conversion as possible. Choose the audio tuning files on the fly in your iDrive. Simply put – elevate your in-car audio experience.

For better sound we strongly recommend adding speakers and woofers to your kit. Here are the options you have available:

• Alpha One by BimmerTech BMW MINI Woofer Set - 2 Woofers
• Alpha One by BimmerTech BMW MINI Front Speakers & Woofer Set - 2 Woofers, 2 Midrange Speakers & 2 Tweeters
• Alpha One by BimmerTech BMW MINI Complete Speakers & Woofer Set -2 Woofers, 4 Midrange Speakers & 2 Tweeters

• Powerful 533MHz Blackfin Digital Signal Processor

• Offers channel mapping, parametric EQ, time alignment, gain control, and much more

• Provides the DSP with as clean of an input signal as possible

• Lets you switch between two of four tuning file banks directly through your iDrive system

• Doesn’t need complicated signal conversion setups

• Has a built-in optical transceiver

• Has a robust variable 4-phase intelligent power supply

• Retains full functionality of the iDrive settings (fader, bass balance, etc.)

Specifications

• 10-channel DSP processor

• 9x speaker level output channels

• 6x 150W MAX for the midrange speakers and tweeter channels @ 4 ohms | 75W RMS

• 2x 300W MAX for the subwoofer channels @ 4 ohms | 150W RMS

• 1x 500W MAX @ 4 ohms (or 800W MAX @ 2 ohms) | 250W RMS (or 400W RMS)

• 1x RCA 4V RMS pre-out for an active trunk sub or a passive sub and additional amplifier

• 90% efficient car audio amplifier

• MOST input

The Life of an Audiophile Made Easy

The first high-end direct replacement and upgrade amplifier for BMWs with Top Hi-Fi audio systems running on optical input signal like Logic 7, Individual Audio, or Harman Kardon.

Thanks to the built-in optical transceiver of Lightwave, you can say goodbye to custom, complex, and very expensive audio setups based on multiple electronic components. Now, instead of a line converter or MOST to analog converter followed by one or more multichannel amplifiers, simply replace your factory amp with Alpha One Lightwave Amplifier.

Less conversion means unparalleled audio quality usually only found in meticulously built home or studio stereo systems. But in the comfort of your BMW cabin!

Optical Magic – All within the Lightwave

The Alpha One Lightwave amplifier can effortlessly receive the optic digital input signal. Why is it important? Well, there are many significant benefits to having an integrated optical transceiver.

Thanks to this built-in input, you retain full functionality of your iDrive fader, bass balance, treble, and multi-band equalizer control – our amp talks to your head unit and does everything the iDrive system tells it to. Even things like phone calls, navigation prompts, or park distance control sounds will continue to be at your disposal, just like from the factory.

Additionally, the audio signal arrives at the Lightwave’s powerful 533MHz Blackfin Digital Signal Processor in its original form without any conversions along the way. This gives the DSP as clean of an input signal as possible, translating into an outstanding sound quality.

Tailored to Your Taste, like All Great Things Should Be

With such a potent DSP as the brain of the operations, Lightwave has everything that’s required for channel mapping, endless amounts of parametric EQ, high/low/band-pass filters, time alignment, gain control, and much more. Needless to say, as always at Alpha One we will set all of those for you and ship your amplifier pre-tuned to sound great right from the get-go.

The Lightwave Amplifier has 4 tuning file banks. What’s even more exciting is that you will be able to switch between 2 of them directly through your iDrive system. All you need to do is toggle the Surround/Logic 7 function on or off to switch things up.

Packaged into a surprisingly small unit, all of the above results in excellent sound quality, even with the factory OEM BMW speakers. And you get a whole kit for plug-an/bd-play implementation.

Please provide your VIN at Checkout for verification

Compatible with 97.4% of BMWs & MINIs.

To ensure the part(s) you have ordered fits your vehicle, we run a compatibility check prior to dispatch. We can do this either using your registration number(UK) or the last 7 digits of your VIN. Simply enter your car details prior to checkout.

Manufactured by

Alpha One by BimmerTech
