4 Piston - Radi-CAL - CP5780
Applications:
- BTCC front.
- WTC front.
Features:
- Radial Mount, 180 x 42mm centres.
- Benefits from a radical new asymetric design concept.
- Superior dynamic performance.
- Increased stiffness.
- Reduced weight.
- Monobloc Aluminium alloy body.
- Suits 343 x 32mm disc.
- Stainless steel or Titanium pistons.
- Carbon duct available.
- Stainless Steel wear plates.
Part Numbers:
- Caliper with Stainless Steel Pistons.
- RHT = CP5780-6S0LP. / - LHT = CP5780-7S0LP.
- RHL = CP5780-8S0LP. / - LHL = CP5780-9S0LP.
- For Titanium pistons replace L suffix with M.
Brake Pad Information
CP5788D48
Pad Area = 63.2cm²
Pad Depth - 48.0mm
Thickness = 20.0mm
Piston Sizes - mm
- 38.1 x 2
- 44.5 x 2
Piston Area cm³ 53.84
Disc Diameter - mm 343.0
Disc Thickness - mm 32.0
Weight (no pads) - Kg
- Stainless Pistons = 2.11
- Titanium Pistons = 1.94
Hydraulic Threads M10x1.0
Mounting Type Radial
Mounting Centres - mm 180.0
Mounting Offset - mm 42.0
Mounting Hole - mm 12.15
PL Dimension - mm 61.7
Bleed Screw Tightening Torque 17Nm
SPARE PARTS
Pistons - Stainless
- 38.1 = CP5990-107
- 44.5 = CP5990-106
Titanium
- 38.1 = CP5789-107
- 44.5 = CP5789-106
Seal Repair Kit CP4518-JL
Wear Plates CP5780-104 x 4
- Ctr Beam = CP5780-105
Dry Break Fitting
(To view more Dry Break information select text above) CP6300-21
Piston Caps CP4528-JL
Dry Break Tightening Torque 13Nm
