| Brake Pad Information (To view larger image of pad click on Pad Part No) |
- Pad Area = 57.4cm² - Pad Depth = 50.3mm - Thickness = 16.8mm |
| TECHNICAL SPECIFICATIONS | |
| Piston Sizes - mm | 38.1 x 2 41.3 x 2 |
| Disc Diameter - mm | 330 |
| Disc Thickness - mm | - Max = 28 - Min = 26 |
| Weight (no pads) - Kg | 2.43 |
| Hydraulic Threads | M10x1.0 |
| Mounting Type | Radial |
| Mounting Centres - mm | 152 |
| Mounting Offset - mm | 46.86 |
| Mounting Hole - mm | 10.1 Nom |
| PL Dimension - mm | 60.36 |
| Bleed Screw Tightening Torque | 17Nm |
| SPARE PARTS | |
| Pistons | - 38.1 = CP9200-108 - 41.3 = CP109 |
| Seal Repair Kit | CP4527-JK |
| Pad Retainer Type / Part No | Bolt - CP5200-104 |
| Pad Retainer Bolt Part No | CP3596-112ST |
| Bleed Screw | CP4970-125 |
| Fluid Pipes | CP9200-10 |
| Pad Anti-Rattle Clip | CP5200-151 |
Feel free to contact us at info@mlperformance.co.uk should you wish to double check!
To ensure the part(s) you have ordered fits your vehicle, we run a compatibility check prior to dispatch. We can do this either using your registration number (UK) or the last 7 digits of your VIN. Simply enter your car details prior to checkout.
AP-RACING-CP9200-4S0BG
Manufactured by
AP RACING
