This is AST Suspension ASTLS-14-1219 Mercedes Lowering Springs.

• Not suitable for cars equiped with standard sportsuspensions.
• Set only contains two rear springs.
• Not suitable for cars with level adjustement.
• Not suitable for 4WD (four-wheel drive) cars.
• Not suitable for station wagons.
• Not suitable for cars with hydropneumatic suspension.
• Not suitable for cabriolet, convertible designs.
• Mounting instructions for W201/202/123/124/126: Max. lowerering is obtained by using single points (single stud) spring rubber bases on the front and rear axles.
• Not suitable for cars with Full Options.
• Only for cars with Full Options.
• For cars with standard lowering, the indicated lowering will be reduced with the amount of the standard lowering.
• Take the rubber that is on the original spring off and put it on the loweringspring on the same place
• The MB E-class S211 has standard level adjustment at the rear. So the car can be lowered at the back by setting the level adjustment. Therefore this set only contains frontsprings.
• Not suitable for cars with multilink rear suspension
• Only suitable for vehicles with multilink rear suspension.
• About 15mm less lowering for vehicles with sportsuspension.
• Only suitable for vehicles with torsion-beam axle
• Cut off 2 rings from the bottomside of the front bumpstops for extra lowering at the front
• Not suitable for 2WD (Two-Wheel Drive) cars
• Set only contains 2 front springs
• Not for configuration codes: SA950 / SA483 + 213, P84, the configuration codes can be taken from the data card of the vehicle
• Only suitable for vehicles to chassis no. 3603470
• Only suitable for vehicles from chassis no. 3603471
• Not suitable for vehicles with AMG suspension
• Only suitable for vehicles from chassis no. 3603471
• Not suitable for vehicles with AMG suspension
• The indicated lowering can differ due to different variants and options
• About 30mm lowering for Vito Crew Van
• Suitable for vehicles with factory comfort suspension (code 485)
• Suitable for vehicles with factory comfort and lowered chassis suspension (code 677)
• About 15-10mm less lowering for vehicles with factory comfort and lowered chassis suspension (code 677)
• Not suitable for vehicles with factory sport suspension / AMG-sport suspension (code 486)
• Suitable for vehicles with factory sport suspension / AMG-sport suspension (code 486)
• Suitable for vehicles with configuration codes: 950/P84, the configuration codes can be taken from the data card of the vehicle
• Not suitable for vehicles with factory comfort suspension (code 485)
• Not suitable for vehicles with factory comfort and lowered chassis suspension (code 677)
• The rear consists of adjustable lowering links
• The adjustment ratios for the rear axle are as follow: Per 1 mm shorter = 10mm lowering on the vehicle. Per 1mm taller is a 10mm taller ride height on the vehicle.

To ensure the part(s) you have ordered fits your need, we run a compatibility check prior to dispatch. Feel free to contact us if you require any assistance!

AST-ASTLS-14-1219

Manufactured by

AST Suspension
