BOOTMOD3 BMW N55 F Chassis (M2, M135i, 235i, 335i, 435i, 535i, 640i, X3, X4, X5 & X6) - ML Performance UK

BOOTMOD3 BMW N20 N26 F Chassis (125i, 220i, 228i, 320i, 328i, 420i, 428i, 520i, 528i)

Bootmod3

  • £429.00
    exc. VAT £357.50
    £357.50

Compatibility Check - Enter your full VIN. We will double check compatibility for you before dispatching!


World's First custom flash tuning platform for the BMW

F Chassis 125i, 220i, 228i, 320i, 328i, 420i, 428i, 520i, 528i



Description

BM3, loud based solution with a web based interface and mobile apps for iOS and Android. Developed and tested in-house from the ground up over the course of almost 2 years prior to its November 2016 debut with new features and updates being added regularly makes the bootmod3 platform a custom BMW factory DME tuning solution like no other on the market today.

Build the ultimate tune for your N20 N26 powered vehicle and go from stock to full race calibration, and everywhere in between, with a map switch in the provided mobile app. bootmod3 calibrates the factory vehicle modules over the OBD port in a matter of minutes in the convenience of your driveway or anywhere internet access is available.



You may also wish to add the Boostmod3 OBD Agent Wifi Device and ML Performance BMW F & G Series OBDII to ENET Cable



Power Gains

The gains depend on map and octane used. Below are the typical gains.

N20 (low-compression 28i)
  • Stage 1 91 octane: 16%HP / 20%TQ
  • Stage 1 93 octane: 18%HP / 22%TQ
  • Stage 2 91 octane: 20%HP / 24%TQ
  • Stage 2 93 octane: 22%HP / 25%TQ
  • Stage 1 E30 octane: 21%HP / 24%TQ
  • Stage 2 E30 octane: 25%HP / 27%TQ

N20 (PWG 20i)

  • Stage 1 91 octane: up to 24%HP / up to 38%TQ
  • Stage 1 93 octane: up to 26%HP / up to 38%TQ
  • Stage 2 91 octane: up to 28%HP / up to 42%TQ
  • Stage 2 93 octane: up to 30%HP / up to 42%TQ
  • Stage 2 E30 octane: up to 33%HP / up to 45%TQ
  • Stage 2 racegas: up to 33%HP / 45%TQ

N20 (EWG 20i)

  • Stage 1 91 octane: 48%HP / 54%TQ
  • Stage 1 93 octane: 52%HP / 56%TQ
  • Stage 2 91 octane: 54%HP / 58%TQ
  • Stage 2 93 octane: 56%HP / 60%TQ



Features

bootmod3 app and cloud services offer many unique features not found in any other flash tune including and currently available:

    1. Mobile app (iOS and Android) and Web (http://www.bootmod3.net)
    2. One OTS map/tune included with the purchase
    3. Datalogging over 200 diagnostic channels, up to 40 channels concurrently
      1. Datalog sharing and charting without a need to upload to 3rd party websites or apps using the mobile app or web browser
    4. Cloud based storage for map data and datalogs
    5. Reverting back to stock performance map and re-locking the DME to stock programming
    6. Live Dash - realtime vehicle parameter monitoring via in-app guages
    7. Diagnostics
      1. Read and clear trouble codes in all vehicle modules
      2. Reset learned adaptations (octane, knock, Valvetronic, etc)
      3. ECU power reset
    8. (Optional) Off the shelf (OTS) tunes for 91/93/Race gas/E85 octane (SEE HERE)
    9. (Optional) Custom tuning available through tuners in the bootmod3 Tuner Directory. bootmod3 contains a full map editor so you can tune your car yourself or with your local tuner of choice as well.



Map Features

- Top speed limiter removal
- Higher rev limiter
- Exhaust burble
- Cold start cat heat cycle and cat efficiency check removed (for off-road use)
- Maps for upgraded turbos
- E85/blend, race gas and meth injection tuning
- Custom Throttle mapping
- Backend Flash maps for use with piggybacks such as the JB4

For more info take a look at the FAQ here!



Compatibility - N20/N26 Engines

BMW F chassis 125i, 220i, 228i, 320i, 328i, 420i, 428i, 520i & 528i with the N20 and N26 engine.

Note: If your car is a March 2019+ model, you may need to visit one of our partner garages to have the car bench unlocked before you can flash your ECU. Please contact us to know more.



Hardware Requirement

*** OBD ENET cable required, available separately



*** bootmod3 OBD WiFi Agent device is not required to use the bootmod3 platform. It is a convenience option that removes the need for using a laptop in the car when using bootmod3's features. If you're looking to simply load a tune on the car without much datalogging and monitoring then using your laptop is the ticket for you.



Installation

DME removal from the engine bay for unlocking OBD programming is NO LONGER REQUIRED.



VEHICLE MANUFACTURER WARRANTY AND EMISSIONS DISCLAIMER

Some items used and/or installed by PRO TUNING FREAKS may void portions of your vehicle’s factory warranty. Some items may not be legal for “on highway use”. PRO TUNING FREAKS makes no guarantees to the legality of any parts used for “on highway vehicles” and accepts no responsibility for compliance with the vehicle’s factory warranty.



Part Nubmer

BM3-003
