BOOTMOD3 BMW N55 F Chassis (M2, M135i, 235i, 335i, 435i, 535i, 640i, X3, X4, X5 & X6) - ML Performance UK

BOOTMOD3 BMW N55 F Chassis (M2, M135i, M235i, 335i, 435i, 535i, 640i, X3, X4, X5 & X6)

Bootmod3

  • £429.00
    exc. VAT £357.50
    £357.50
  • 2 reviews

Compatibility Check - Enter your full VIN. We will double check compatibility for you before dispatching!


World's First custom flash tuning platform for the BMW

F Chassis M2, M135i, 235i, 335i, 435i, 535i, 640i, X3, X4, X5 & X6



Description

BM3, cloud based solution with a web based interface and mobile apps for iOS and Android. Developed and tested in-house from the ground up over the course of almost 2 years prior to its November 2016 debut with new features and updates being added regularly makes the bootmod3 platform a custom BMW factory DME tuning solution like no other on the market today.

Build the ultimate tune for your N55 powered vehicle and go from stock to full race calibration, and everywhere in between, with a map switch in the provided mobile app. bootmod3 calibrates the factory vehicle modules over the OBD port in a matter of minutes in the convenience of your driveway or anywhere internet access is available.



You may also wish to add the Boostmod3 OBD Agent Wifi Device and ML Performance BMW F & G Series OBDII to ENET Cable



Features

bootmod3 app and cloud services offer many unique features not found in any other flash tune including and currently available:

    1. Mobile app (iOS and Android) and Web (http://www.bootmod3.net)
    2. One OTS map/tune included with the purchase
    3. Datalogging over 200 diagnostic channels, up to 40 channels concurrently
      1. Datalog sharing and charting without a need to upload to 3rd party websites or apps using the mobile app or web browser
    4. Cloud based storage for map data and datalogs
    5. Reverting back to stock performance map and re-locking the DME to stock programming
    6. Live Dash - realtime vehicle parameter monitoring via in-app guages
    7. Diagnostics
      1. Read and clear trouble codes in all vehicle modules
      2. Reset learned adaptations (octane, knock, Valvetronic, etc)
      3. ECU power reset
    8. (Optional) Off the shelf (OTS) tunes for 91/93/Race gas/E85 octane (SEE HERE)
    9. (Optional) Custom tuning available through tuners in the bootmod3 Tuner Directory. bootmod3 contains a full map editor so you can tune your car yourself or with your local tuner of choice as well.



Power Gains

N55 pneumatic wastegate (PWG):
Stage 1 91: 19%HP / 28%TQ
Stage 1 93: 21%HP / 30%TQ
Stage 2 91: 25%HP / 34%TQ
Stage 2 93: 27%HP / 36%TQ



N55 electronic wastegate (EWG):
Stage 1 91: 25%HP / 28%TQ
Stage 1 93: 27%HP / 30%TQ
Stage 2 91: 31%HP / 34%TQ
Stage 2 93: 33%HP / 36%TQ



Map Features

- Top speed limiter removal
- Higher rev limiter
- Exhaust burble
- Cold start cat heat cycle and cat efficiency check removed (for off-road use)
- Maps for upgraded turbos
- E85/blend, race gas and meth injection tuning
- Custom Throttle mapping
- Backend Flash maps for use with piggybacks such as the JB4



For more info take a look at the FAQ here!



Compatibility - N55 Engines

  • M135 2012 - 2015
  • M235 2013 - 2016
  • M2 2016 - 2018
  • 335i 2011 - 2015
  • 335i ActiveHybrid 2012 - 2015
  • 435i 2013 - 2016
  • 535i 2011 - 2017
  • 535i ActiveHybrid 2011 - 2017
  • 640i 2012 - 2017
  • 740i 2011 - 2016
  • X3 35i 2010 - 2017
  • X4 M40i 2015 - 2017
  • X5 40i 2013 - 2017
  • X6 40i 2014 - 2017



Please enquire with us if your vehicle is not listed here.

Note: If your car is a March 2019+ model, you may need to visit one of our partner garages to have the car bench unlocked before you can flash your ECU. Please contact us to know more.



Hardware Requirement

*** OBD ENET cable required, available separately



*** bootmod3 OBD WiFi Agent device is not required to use the bootmod3 platform. It is a convenience option that removes the need for using a laptop in the car when using bootmod3's features. If you're looking to simply load a tune on the car without much datalogging and monitoring then using your laptop is the ticket for you.



Installation

DME removal from the engine bay for unlocking OBD programming is NO LONGER REQUIRED.



VEHICLE MANUFACTURER WARRANTY AND EMISSIONS DISCLAIMER

Some items used and/or installed by PRO TUNING FREAKS may void portions of your vehicle’s factory warranty. Some items may not be legal for “on highway use”. PRO TUNING FREAKS makes no guarantees to the legality of any parts used for “on highway vehicles” and accepts no responsibility for compliance with the vehicle’s factory warranty.



Identifying Wastegate Type
