- Mobilgrease 33 is a high-performance lithium-complex grease designed for general-purpose aircraft use.
- Its consistency is between the NLGI grades 1 and 2.
- Mobilgrease 33 utilizes a 100% polyalphaolefin base oil and premium additives which ensure outstanding lubrication performance over a wide temperature range and operating conditions.
Specification and Approvals
|
Property |
|
|
Grade |
NLGI 1.5 |
|
Al/Ni Bronze Corrosiveness, 24 h, 100 C, Rating, SAE AMS3058 3.2.7.b |
PASS |
|
Base Oil Viscosity of Greases @ 100 C, mm2/s, AMS 1700 |
3.2 |
|
Base Oil Viscosity of Greases @ 40 C, mm2/s, AMS 1697 |
12.5 |
|
Boeing Dynamic Bearing Life, cycles, BMS 3-33 |
PASS |
|
Bomb Oxidation, Pressure Drop, 100 h, kPa, ASTM D942 |
11 |
|
Color, Visual |
Blue Green |
|
Copper Strip Corrosion, 24 h, 100 C, Rating, ASTM D4048 |
1B |
|
Dirt, # particles 25u to 74 u, FTM 3005 |
0 |
|
Dirt, # particles 75u or larger, FTM 3005 |
0 |
|
Dropping Point, °C, ASTM D2265 |
255 |
|
EMCOR Rust, 3% NaCl, IP 220 |
0,0 |
|
Evaporation Loss, 22 h, 100 C, mass%, ASTM D2595 |
1 |
|
Evaporation Loss, 500 h, 121 C, mass %, ASTM D2595 |
8.7 |
|
Four-Ball Extreme Pressure Test, Weld Load, kgf, ASTM D2596 |
700 |
|
Four-Ball Wear Test, Scar Diameter, mm, ASTM D2266 |
0.4 |
|
Fretting Wear, mg, ASTM D4170 |
0.6 |
|
Gear Wear Test, 2.3 kg load, 1000 cycles, gear wt loss, mg, FTM 335 (mod) |
1.1 |
|
Gear Wear Test, 4.5 kg load, 1000 cycles, gear wt loss, mg, FTM 335 (mod) |
1.6 |
|
High Temperature Performance, Hrs at 121 C, h, ASTM D3336 |
2,200+ |
|
Load Carrying Capacity, Load-Wear Index, kgf, ASTM D2596 |
110 |
|
NBR-L, AMS 3217/2 Compat, 70C 158 h, vol %, FTM 3603 |
12.6 |
|
Odor, OLFACTORY |
PASS |
|
Oil Separation, 30 h @ 100 C, mass%, ASTM D6184 |
4 |
|
Oxidation Stability, Pressure Drop, 500 h, kPa, ASTM D942 |
25 |
|
Penetration, 60X, 0.1 mm, ASTM D217 |
292 |
|
Penetration, Unworked, 0.1 mm, ASTM D217 |
285 |
|
Rust Protection, 48 h @ 125 F, Rating, ASTM D1743 |
0,0,0 |
|
Texture/Consistency, VISUAL |
PASS |
|
Timken OK Load, lb, ASTM D2509 |
55 |
|
Water Washout, Loss @ 38 C, wt%, ASTM D1264 |
3 |
|
Water Washout, Loss @ 79 C, wt%, ASTM D1264 |
6 |
|
Pen Worked X 100,000, 1/16" holes, 0.1 mm, FTM 313 |
330 |
|
Low Temperature Torque, Starting @ -73 C, Nm, ASTM D1478 |
0.52 |
|
Low Temperature Torque, Running @ -73 C, Nm, ASTM D1478 |
0.06 |
Applications
Mobil grease 33 is a true multipurpose aviation grease intended for use in highly loaded anti-friction bearings, gears, and actuators as well as instruments, high speed bearings (though not recommended for wheel bearings), and general airframe lubrication, over operating temperatures from 100ºF to 250ºF (73ºC to 121ºC). It can be used in all applications for which the aircraft manufacturer specifies U.S. Military Specification MIL-PRF-23827, Type I (Grease, Aircraft and Instrument, Gear and Actuator Screw, Grease thickened with metallic soap), Boeing BMS 3-33C (Grease, Aircraft, General Purpose), and Airbus AIMS09-06-002/SAE AMS3052 (Grease, General Purpose, Airframe, Low Temperature Range, Lithium Thickened). Mobil grease 33 is listed in the Qualified Products List of Airbus, Boeing, and the U.S. Military for these specifications. The NATO Code Number for Mobil grease 33 is G-354.
Pack Quantity: 40 units of M-GREASE 33 CART 0.38KG/13.4OZ
