Features and Benefits
Mobilgrease FM 101 and FM 222 belong to the Mobilgrease brand of products, which has gained a worldwide reputation for innovation and performance excellence. Mobilgrease FM 101 and FM 222 are designed by ExxonMobil formulation technologists and backed by its worldwide technical support staff.
Mobilgrease FM 101 and FM 222 greases have been designed specifically to meet the needs of the food processing industry that requires excellent water resistance, rust protection and a lubricant able to provide oil to the load zones reliably under high shear conditions. These greases offer the following features and potential benefits:
Features
|
Advantages and Potential Benefits
|
Excellent water resistance and rust protection
|
Helps provide superb equipment protection during frequent equipment cleaning operations
|
Excellent thickener shear stability
|
Product exhibits excellent stability for long periods of time, helping to provide oil more consistently between relubrication cycles
|
NSF H1 registered, DIN51825certified, Kosher/Parve, Halal
|
Engineered to meet global requirements, presenting a multi-purpose solution to the food processing industry around the world
|
Manufactured in facilities registered to ISO 21469
|
Product integrity assurance through independent verification
|
Specification and Approvals
This product has the following builder approvals:
|
FM 101
|
FM 222
|
IFANCA Halal
|
X
|
X
|
Kosher Certification Council Kosher & Parve
|
X
|
X
|
This product is recommended for use in applications requiring:
|
FM 101
|
FM 222
|
Fives Cincinnati P-64
|
|
X
|
Fives Cincinnati P-72
|
X
|
|
This product is registered to the requirements of:
|
FM 101
|
FM 222
|
NSF H1
|
X
|
X
|
This product meets or exceeds the requirements of:
|
FM 101
|
FM 222
|
DIN 51825:2004-06 - KPF 1 K -20
|
X
|
|
DIN 51825:2004-06 - KPF 2 K -20
|
|
X
|
FDA 21 CFR 178.3570
|
X
|
X
|
Specification and Approvals
Property
|
FM 101
|
FM 222
|
Grade
|
NLGI 1
|
NLGI 2
|
Thickener Type
|
Aluminium Complex
|
Aluminium Complex
|
Color, Visual
|
White
|
White
|
Corrosion, Cu 24H at 120C, Rating, DIN 51811
|
1
|
1
|
Dropping Point, °C, ASTM D2265
|
260
|
260
|
FAG FE9, 1500 N, 6000 RPM, Unshielded at 120C, L50 hrs., DIN 51821
|
120
|
120
|
Four-Ball Extreme Pressure Test, Weld Point, kgf, ASTM D2596
|
315
|
315
|
Four-Ball Wear Test, Scar Diameter, mm, ASTM D2266
|
0.5
|
0.5
|
Penetration, 60X, 0.1 mm, ASTM D217
|
325
|
280
|
SKF Emcor Rust Test, Distilled Water, ASTM D6138
|
0 , 0
|
0 , 0
|
Viscosity @ 40 C, Base Oil, mm2/s, ASTM D445
|
100
|
220
|
Applications
Mobilgrease FM 101 and FM 222 greases are recommended for multi-purpose lubrication of food processing equipment where NSF H1 registration is required. The food industry includes food processing, beverage and packing industries for a wide range of cultures.
Applications include:
General rotating equipment lubrication
Conveyor bearings
Equipment central lubrication systems (Mobilgrease FM 101)
Anti-friction roller bearings under heavy or shock loading
Linkages and slides
Joints
